MultiScreen^® Filter Plates for Enzyme Assays

Enzymes, such as those involved in signal transduction pathways, are critical to the control and regulation of virtually all cellular functions. It is not surprising, therefore, that signaling enzymes such as the protein kinases and phosphatases are under intense investigation in both basic research and drug discovery programs. Recent advances made in unraveling the mechanisms of these enzymes, in addition to the development of powerful high throughput screening technologies, have lead to more specific and reliable screening techniques.

The MultiScreen_HTS Assay System allows you to reliably perform these assays in one filter-bottomed, multiwell plate. This not only saves time, conserves samples, produces less solvent and radioactive waste, and enhances consistency, but it also makes complete automation easy for most popular plate-based assays. Because these techniques utilize a separations step (or steps), their use generally results in more specific, reliable "leads." Cell-based assays can especially lead to bioactivities more related to those found in vivo.

Available in a wide variety of membrane and plate materials, the MultiScreen_HTS system is extremely versatile. It can be used to perform numerous enzyme assays, such as kinases, phosphatases, proteases, and endonucleases, and a number of second messenger assays such as cAMP, cGMP, phosphodiesterases (PDE), Nitric Oxide (NO), Ca²⁺, and inositols.

Different filter materials allow for low or high protein- and DNA-binding, ion-exchange, and solvent resistance. Recommended filter types for enzyme assays include:

Low protein-binding PVDF (HV, DV)

• High protein-binding mixed cellulose esters (HA)

• High protein-binding hydrophobic PVDF (IP)

• Negatively charged phosphocellulose (PH)

• Positively charged DEAE (DE)

• Glass fiber (FB, FC)

The assorted available filters, with inherently different retention and separation characteristics, can be exploited to implement fundamental separation techniques in both 96- and 384-well
formats.

MultiScreen_HTS+ Hi Flow filter plates: improve washing efficiency and reduce data variability.

Protocol

MultiScreen_HTS Filter Plates

The new HTS design for both 96- and 384-well filter plates features rigid sidewalls aligned for robotic gripper arms. They also provide ample surfaces for barcode labels. The plate design eliminates surface contact with individual well “drip directors.” A plastic skirt improves the vacuum seal when used with a Millipore MultiScreen™_HTS vacuum
manifold.

Use of 384-well plates offers the reagent saving benefits of assay miniaturization and less waste. Results with the 384-well plate are shown to be equivalent to 96-well results.

Enzyme assays are widely used in life science research and compound screening. Filter plates, by facilitating the separation of the products from the reactants in enzymatic reactions, enable reliable, highly sensitive, and automation-compatible assays. MultiScreen^®HTS filter plates set the standard for filtration-based enzyme assays. These versatile systems are widely used for kinase, phosphatase, protease and endonuclease assays, as well as second messenger assays such as for cAMP, cGMP, phosphodiesterase (PDE), Nitric Oxide (NO), Ca2+ and inositols. The filtration-based protocol produces specific, reliable results that are well-referenced in the literature.
