572349

Yttria stabilized zirconia

greener alternative

nanopowder

Synonym(s):

Zirconium(IV) oxide-yttria stabilized, YSZ, Yttria stabilized zirconia, Yttrium stabilized zirconium oxide

Sign In to View Organizational & Contract Pricing.

Select a Size

About This Item

Linear Formula:
ZrO2 · Y2O3
CAS Number:
114168-16-0
Molecular Weight:
349.03
UNSPSC Code:
26111700
PubChem Substance ID:
329758284
NACRES:
NA.23
MDL number:
MFCD00145546

Key Documents

View All Documentation
Technical Service
Need help? Our team of experienced scientists is here for you.
Let Us Assist
Technical Service
Need help? Our team of experienced scientists is here for you.
Let Us Assist

Product Name

Zirconium(IV) oxide-yttria stabilized, nanopowder

SMILES string

O=[Zr]=O.O=[Y]O[Y]=O

InChI

1S/5O.2Y.Zr

InChI key

KSTOPEBVPBSOTK-UHFFFAOYSA-N

assay

92% ZrO2 basis

form

nanopowder

contains

8 mol % yttria as stabilizer

composition

(ZrO2)0.92(Y2O3)0.08

greener alternative product characteristics

Design for Energy Efficiency
Learn more about the Principles of Green Chemistry.

sustainability

Greener Alternative Product

surface area

>100 m2/g

particle size

≤100 nm, 5-10 nm (crystallite size)

mp

>2,600 °C (lit.)

greener alternative category

, Enabling

Quality Level

100

Looking for similar products? Visit Product Comparison Guide

Related Categories

Application

Collagen-yttria-stabilized amorphous zirconia hybrid scaffolds may be developed. YSZ thin films may be used as thermal barrier coatings on combustors, stationary and rotating components of gas turbines or diesel engines. 6
Electrolyte material for solid oxide fuel cells (SOFC).
YSZ can be used for a variety of applications such as:
  • a thermal barrier coating for the protection and insulation of metal components in gas turbines
  • an electrolyte in the fabrication of solid oxide fuel cells (SOFCs)
  • in the fabrication of zirconia dental implant abutments
  • membranes for micro energy conversion devices
  • a solid acid and a catalyst for catalytic applications

General description

We are committed to bringing you Greener Alternative Products, which adhere to one or more of The 12 Principles of Greener Chemistry. This product has been enhanced for energy efficiency. Click here for more details.
Yttria-stabilized zirconia (YSZ) is the most commonly used solid electrolyte for solid oxide fuel cells (SOFCs) and oxygen sensors. YSZ exhibits high oxygen-ionic conductivity while blocking electronic conduction. YSZ particles may be synthesized from yttrium nitrate or isopropoxide by sol gel method. YSZ nanoparticles may be prepared in supercritical water (SCW). YSZ nanoparticles of different sizes with varying % mol of yttria may be obtained by CO2 laser based continuous/pulsed laser vaporization method.
Zirconium(IV) oxide-yttria stabilized (YSZ) (nanopowder) is an oxygen ion conductor with properties such as good ionic conductivity and high physiochemical stability. Its other properties include excellent shock resistance, low thermal conductivity and a high coefficient of thermal expansion.

Other Notes

Alternative CAS number: 114168-16-0

Packaging

Packaged in glass bottles

pictograms

Exclamation mark
GHS07

signalword

Warning

Hazard Classifications

Eye Irrit. 2 - Skin Irrit. 2 - STOT SE 3

target_organs

Respiratory system

Storage Class

11 - Combustible Solids

wgk

WGK 3

flash_point_f

Not applicable

flash_point_c

Not applicable

ppe

dust mask type N95 (US), Eyeshields, Gloves

Regulatory Listings

Regulatory Listings are mainly provided for chemical products. Only limited information can be provided here for non-chemical products. No entry means none of the components are listed. It is the user’s obligation to ensure the safe and legal use of the product.

Substances Subject to be Indicated Names

ishl_indicated

Substances Subject to be Notified Names

ishl_notified

572349-25G:4548173956060 + 572349-BULK: + 572349-VAR:

jan

Choose from one of the most recent versions:

Certificates of Analysis (COA)

Lot/Batch Number
MKCD6749
MKCD6748
MKCC0757
MKBZ5387V
MKBZ5504V

Don't see the Right Version?

If you require a particular version, you can look up a specific certificate by the Lot or Batch number.

Search for a COA

Already Own This Product?

Find documentation for the products that you have recently purchased in the Document Library.

Visit the Document Library

Zigzag or spiral-shaped nanostructures improve mechanical stability in yttria-stabilized zirconia membranes for micro-energy conversion devices
Shi Y, et al.
Nano Energy, 59(1), 674-682 (2019)
Fracture resistance of yttria-stabilized zirconia dental implant abutments
Adatia ND, et al.
Journal of Prosthodontics : Official Journal of the American College of Prosthodontists, 18(1), 17-22 (2009)
Confined Transformation of UiO-66 Nanocrystals to Yttria-Stabilized Zirconia with Hierarchical Pore Structures for Catalytic Applications
Qin R and Zeng H
Advances in Functional Materials, 29(39), 1903264-1903264 (2019)
Thermodynamic vaporization studies of the manganese oxide--yttria stabilized zirconia (YSZ) solid solution
Matraszek A, et al.
J. Eur. Ceram. Soc., 24(9), 2649-2656 (2004)
Impedance spectroscopy of pellets made from yttria stabilized zirconia nanoparticles generated via CW and pulsed mode of laser vaporization method
Khare J, et al.
Ceramics International, 40(9) Part B, 14677-14685 (2014)
