Merck

241903

Aluminum nitride

powder, 10 μm, ≥98%

Synonym(s):

Aluminium nitride, Azanylidynealumane

Sign In to View Organizational & Contract Pricing.

Select a Size

About This Item

Linear Formula:
AlN
CAS Number:
24304-00-5
Molecular Weight:
40.99
NACRES:
NA.23
PubChem Substance ID:
24854500
UNSPSC Code:
12352300
EC Number:
246-140-8
MDL number:
MFCD00003429

Key Documents

View All Documentation
Technical Service
Need help? Our team of experienced scientists is here for you.
Let Us Assist
Technical Service
Need help? Our team of experienced scientists is here for you.
Let Us Assist

assay

≥98%

form

powder

particle size

10 μm

mp

>2200 °C (lit.)

density

3.26 g/mL at 25 °C (lit.)

SMILES string

N#[Al]

InChI

1S/Al.N

InChI key

PIGFYZPCRLYGLF-UHFFFAOYSA-N

Looking for similar products? Visit Product Comparison Guide

Related Categories

General description

Aluminum Nitride(AlN) is a non-oxide semiconductor material with a hexagonal Wurtzite crystal structure. It has a wide direct bandgap of 6.12 eV. AIN is a suitable additive in making thermal grease and electric cable insulation owing to its very high thermal conductivity (300 W/(m. K)) and electrical resistivity. It is also used in microelectronics, electroluminescent devices, and sensors because of its non-toxicity, superior thermal, electrical, mechanical, and chemical properties.

Application

Aluminum Nitride can be used as a:
  • ceramic material in the preparation of nano capsulated phase change material for building thermal management systems.
  • matrix in the preparation of metacomposites along with graphene platelets to improve their thermal conductive properties.
  • foaming agent in the preparation of foam glass using glass waste.
It is also used to prepare ceramic matrix composite material along with molybdenum to generate high-energy X-rays.

pictograms

Health hazardEnvironment
GHS08,GHS09

signalword

Danger

hcodes

H372,H410

Hazard Classifications

Aquatic Acute 1 - Aquatic Chronic 1 - STOT RE 1 Inhalation

target_organs

Lungs

Storage Class

4.3 - Hazardous materials which set free flammable gases upon contact with water

flash_point_f

Not applicable

flash_point_c

Not applicable

ppe

dust mask type N95 (US), Eyeshields, Gloves

wgk

WGK 2

Regulatory Listings

Regulatory Listings are mainly provided for chemical products. Only limited information can be provided here for non-chemical products. No entry means none of the components are listed. It is the user’s obligation to ensure the safe and legal use of the product.

241903-BULK: + 241903-250G: + 241903-VAR: + 241903-50G:

jan

Choose from one of the most recent versions:

Certificates of Analysis (COA)

Lot/Batch Number

It looks like we've run into a problem, but you can still download Certificates of Analysis from our Documents section.

If you need assistance, please contact Customer Support

Already Own This Product?

Find documentation for the products that you have recently purchased in the Document Library.

Visit the Document Library

Novel hybrid composite phase change materials with high thermal performance based on aluminium nitride and nanocapsules
Lu Wang, et al.
Energy, 238, 121775-121775 (2022)
Band structure and fundamental optical transitions in wurtzite AlN
Li, Jing, et al.
Applied Physics Letters, 83(25), 5163-5165 (2003)
Mohammad T Baei et al.
Journal of molecular modeling, 18(9), 4477-4489 (2012-05-31)
Structural, electronic, and electrical responses of the H-capped (6,0) zigzag single-walled aluminum nitride nanotube was studied under the parallel and transverse electric fields with strengths 0-140 × 10(-4) a.u. by using density functional calculations. Geometry optimizations were carried out at the B3LYP/6-31G* level
Norio Iizuka et al.
Optics express, 17(25), 23247-23253 (2010-01-07)
Spot-size converters for an all-optical switch utilizing the intersubband transition in GaN/AlN multiple quantum wells are studied with the purpose of reducing operation power by improving the coupling efficiency between the input fiber and the switch. With a stair-like spot-size
Javad Beheshtian et al.
Journal of molecular modeling, 18(10), 4745-4750 (2012-06-09)
Single-walled aluminum nitride nanotubes (AlNNTs) are introduced as an electronic sensor for detection of sulfur dioxide (SO₂) molecules based on density functional theory calculations. The proposed sensor benefits from several advantages including high sensitivity: HOMO-LUMO energy gap of the AlNNT
