901975
SunTronic® silver nanoparticle ink for inkjet printing
sintering temperature 100 - 150°C
別名:
Ag ink, Conductive ink, Silver ink, SunTronic®EMD5800
で組織・契約価格をご覧ください。
サイズを選択してください
表示を変更する
この商品について
実験式（ヒル表記法）:
Ag
分子量:
107.87
NACRES:
NA.23
UNSPSC Code:
12352200
description
Silver content: 45-50%, Sintering temperature: 100 - 150°C for 10 – 60 min, Solid content: 48-52%, Volume Resistivity: 5 – 25 uΩcm
form
liquid
surface tension
25-28 dyn/cm
viscosity
6-8 cP (Brookfield)
storage temp.
2-8°C
General description
SunTronic® Nanosilver EMD5800 series is formulated for non-contact printing of conductive traces onto a variety of substrates.
EMD5800 is oil-based nanoparticle inks which demonstrates superior conductivity at low sintering temperatures with stable jetting performance and adhesion to temperature sensitive plastics.
It can be used in the manufacture of touch panel displays, printed RFID antennae, smart cards, sensors, security labels, touch switches and other printed electronics applications.
EMD5800 is oil-based nanoparticle inks which demonstrates superior conductivity at low sintering temperatures with stable jetting performance and adhesion to temperature sensitive plastics.
It can be used in the manufacture of touch panel displays, printed RFID antennae, smart cards, sensors, security labels, touch switches and other printed electronics applications.
Legal Information
SunTronic is a registered trademark of Sun Chemical, Inc.
Disclaimer
Printing
EMD5800 is supplied as ready-to-use oil based inks, and can be printed on various deposition printers and jetted on through various piezo DOD inkjet printheads suitable for oil based inks, although full printhead compatibility will need to be verified in each case
EMD5800 is supplied as ready-to-use oil based inks, and can be printed on various deposition printers and jetted on through various piezo DOD inkjet printheads suitable for oil based inks, although full printhead compatibility will need to be verified in each case
Sintering
Sintering conditions may change for different ink film thicknesses. Typical sintering temperature may range from 100-200°C depending on temperature tolerance of the substrate. Sintering time may range from 10-60 minutes. Electrical resistance may be reduced with higher sintering temperature and/or longer sintering times.
Sintering conditions may change for different ink film thicknesses. Typical sintering temperature may range from 100-200°C depending on temperature tolerance of the substrate. Sintering time may range from 10-60 minutes. Electrical resistance may be reduced with higher sintering temperature and/or longer sintering times.
Storage
Refrigerated storage at a temperature of 5-15°C is recommended. Agitation after refrigeration to assure proper dispersion is recommended.
Refrigerated storage at a temperature of 5-15°C is recommended. Agitation after refrigeration to assure proper dispersion is recommended.
Still not finding the right product?
Explore all of our products under SunTronic® silver nanoparticle ink for inkjet printing
signalword
Danger
hcodes
Hazard Classifications
Aquatic Acute 1 - Aquatic Chronic 1 - Asp. Tox. 1 - Eye Dam. 1 - Skin Corr. 1B - STOT RE 2 Oral
target_organs
Gastrointestinal tract,Liver,Immune system
保管分類
8A - Combustible corrosive hazardous materials
wgk
WGK 3
flash_point_f
156.2 °F
flash_point_c
69 °C
適用法令
試験研究用途を考慮した関連法令を主に挙げております。化学物質以外については、一部の情報のみ提供しています。 製品を安全かつ合法的に使用することは、使用者の義務です。最新情報により修正される場合があります。WEBの反映には時間を要することがあるため、適宜SDSをご参照ください。
Class I Designated Chemical Substances
prtr
Group 4: Flammable liquids + Type 2 petroleums + Hazardous rank III + Water insoluble liquid
fsl
Substances Subject to be Indicated Names
ishl_indicated
Substances Subject to be Notified Names
ishl_notified
901975-10ML:4.548173360621E12 + 901975-2ML:4.548173360638E12
jan
