915874
Al-doped lithium lanthanum zirconium oxide LLZO
solid electrolyte, powder, battery grade
別名:
Aluminum-doped cubic garnet LLZO, LLZALO
ログインで組織・契約価格をご覧ください。
サイズを選択してください
表示を変更する
この商品について
製品名
Al-doped lithium lanthanum zirconium oxide (LLZO), solid electrolyte, powder, battery grade
grade
battery grade
Quality Segment
assay
≥99.5%
form
powder
mol wt
Mw 840.62 g/mol
composition
Li6.24La3Zr2Al0.24O11.98
surface area
0.50 m2/g
particle size
5-6 μm (average)
conductivity
0.01-0.1 mS/cm (Ionic conductivity, unsintered, cold-pressed pellet at RT)
density
5.093 g/cm3 (lit.)
application(s)
battery manufacturing
General description
Battery-grade Al-doped Lithium Lanthanum Zirconate Oxide (LLZO) powder is a high-purity, inorganic material that is specifically designed for use in advanced battery applications. It is a white, crystalline powder with an average particle size of 5-6 microns and is composed of lithium, lanthanum, zirconium, oxygen, and a small amount of aluminum dopant. This material is known for its high ionic conductivity, which falls within the range of 0.01-0.1 mS/cm, making it an ideal electrolyte material for use in solid-state lithium-ion batteries. Moreover, the high purity and narrow particle size distribution of this powder make it well-suited for use in the precise and reproducible manufacturing of battery components.
Application
The primary application of Al-doped LLZO powder is in all-solid-state and hybrid electrolytes for lithium-ion batteries. The unique combination of properties, including its high lithium-ion conductivity, robust chemical stability, and wide electrochemical stability window, make it a promising candidate for the next generation of solid-state batteries. This material has the potential to replace the conventional liquid electrolyte in lithium-ion batteries, offering higher energy density, improved safety, and longer lifespan.
Features and Benefits
Our LLZO powder provides high ionic conductivity and consistent particle size for reproducible results.
- Improved Battery Safety
- Increased Energy Density
signalword
Danger
hcodes
Hazard Classifications
Eye Dam. 1 - Skin Corr. 1B - STOT SE 3
target_organs
Respiratory system
保管分類
8A - Combustible corrosive hazardous materials
flash_point_f
Not applicable
flash_point_c
Not applicable
適用法令
試験研究用途を考慮した関連法令を主に挙げております。化学物質以外については、一部の情報のみ提供しています。 製品を安全かつ合法的に使用することは、使用者の義務です。最新情報により修正される場合があります。WEBの反映には時間を要することがあるため、適宜SDSをご参照ください。
Substances Subject to be Indicated Names
ishl_indicated
Substances Subject to be Notified Names
ishl_notified
