923192

Spiro-TTB

greener alternative

≥99% (HPLC)

Synonym(s):

2,2′,7,7′- Tetrakis(N,N′-di-p-methylphenylamino)-9,9′-spirobifluorene, 2,2′,7,7′-Tetra(N, N-di-tolyl)amino-spiro-bifluorene, 2,2′,7,7′-Tetra(N,N-di-p-tolyl)amino-9,9-spirobifluorene, 2,2′,7,7′-Tetra(N,N-ditolylL)amino-9,9-spiro-bifluorene, 2,2′,7,7′-Tetrakis(di-p-tolylamino)-9,9′-spirobi[fluorene], 2,2′,7,7′-Tetrakis(di-p-tolylamino)spiro-9,9′-bifluorene, N2,N2,N2′,N2′,N7,N7,N7′,N7′-Octa-p-tolyl-9,9′-spirobi[fluorene]-2,2′,7,7′-tetraamine

Sign In to View Organizational & Contract Pricing.

Select a Size

Change View

About This Item

Empirical Formula (Hill Notation):
C81H68N4
CAS Number:
515834-67-0
Molecular Weight:
1097.43
UNSPSC Code:
41116105
NACRES:
NA.23
MDL number:
MFCD28968052
Technical Service
Need help? Our team of experienced scientists is here for you.
Let Us Assist

Quality Segment

100

description

Hole Transport Layer, PL:409 nm (in THF)
TGA:> 360 °C (0.5% weight loss)
Tg: 146 °C

assay

≥99% (HPLC)

mol wt

average mol wt 1097.43 g/mol

greener alternative product characteristics

Design for Energy Efficiency
Learn more about the Principles of Green Chemistry.

sustainability

Greener Alternative Product

loss

0.5% TGA, >360°C

transition temp

Tg 146 °C

solubility

THF: soluble

λmax

385 nm in THF

orbital energy

HOMO 5.2 eV , LUMO 1.9 eV

greener alternative category

, Enabling

General description

We are committed to bringing you Greener Alternative Products, which adhere to one or more of The 12 Principles of Greener Chemistry. This product belongs to enabling category of greener alternatives, and has been enhanced for energy efficiency. Click here for more information.

Application

Spiro-TTB is used as a hole transport material in OLED devices, organic photovoltaics (OPVs), organic field-effect transistors (OFETs) and perovskite solar cells. It exhibits excellent hole injection and transport properties, enabling efficient charge transport from the anode to the emitting layers of the OLED structure. This contributes to improved device performance, stability, and overall efficiency.
Spiro-TTB is a high-mobility organic semiconductor with strong donor character given its four substituted arylamine moieties that stabilize positively charged cationic states via mesomeric effects.
It has been successfully applied as transparent hole-transparent layer in solar cells, organic field-effect transistors (OFETs), and organic light emitting devices (OLEDs). In photovoltaics, spiro-TTB was used as organic hole selective layer between perovskite and the silicon cells, contributing to a 25.2% efficency perovskite/ silicon tandem solar cell. When used in OLEDs, spiro-TTB enabled applications in organic photodetectors (OPDs), imaging and lasing applications.

Storage Class

11 - Combustible Solids

wgk

WGK 3

flash_point_f

Not applicable

flash_point_c

Not applicable
